grips
Schindelhauer
fork
curved aluminium fork for disc brake mount
headset
Tange Seiki - integrated, 1 1/8
max . total weight
130 kg (bike + rider + luggage)
seatpost
Schindelhauer
saddle
Schindelhauer
brakes
Shimano – MT200 disc brakes (hydraulic) 160 mm
stem
Schindelhauer
mudguards
Curana – Apollo (extrusion profile mudguards)
handlebar
Schindelhauer - Jane, Aluminium
lighting
Busch und Müller Lumotec Eyc N Plus front and ILU jr. rear
frame
Aluminium (AL6061-T6), triple butted aero tubing, forged dropouts with slider-belt-tensioning-system and Schindelhauer belt port, points for frame mounted front rack, smooth welded
gear shift
Shimano - Nexus 8-speed
crank set
Gates Carbon Drive - S150
pannier rack
Schindelhauer - aluminium , frame mounted, with VarioStraps
bottom bracket
THUN - Zumba
additional features
Pletscher Twin stand Mounting of bottle cage or lock onto the frame is possible Attaching a child seat onto the seat tube is possible Installing a bicycle trailer onto the rear axle is possible but will require a hub hitch adapter. Please consult the trailer manufacturer or dealer for further information
wheels
Shimano - DH-T4050 hub dynamo, Shimano Nexus 8-speed, Alexrims - DP23 27,5“ rims, SAPIM spokes, 3-cross and 2-cross laced
weight
13.0 kg
pedals
VP - Nylon, with grip tape
tyres
WTB - Horizon 47 - 584, with reflex stripes
power transmission
Gates Carbon Drive - CDN, front 46T, rear 24T, belt 115T
